Mz Geomagnetic Quantum Magnetometer V 1.0

Category: Quantum Magnetometer
Model: QTFM-Mozi 1.0
Type: Optically Pumped Scalar Magnetometer

The QTFM-Mozi Series Geomagnetic Magnetometer is a next-generation scalar atomic magnetometer engineered for ultra-precise geomagnetic measurements.

Leveraging the Larmor precession of alkali metal atoms, it achieves exceptional sensitivity and long-term stability, enabling reliable detection of subtle magnetic anomalies.

Its compact, low-power design makes it highly adaptable to both fixed installations and mobile platforms, including UAV-based survey systems.

The QTFM-Mozi series delivers a high-performance solution for advanced magnetic sensing, supporting applications in mineral exploration, industrial inspection, and quantum measurement.





Technical Specifications
Parameter Specification Parameter Specification
Type Optically Pumped Rubidium Scalar Magnetometer Magnetic Probe Size 15mm*15mm*30mm
Sensitivity 10 pT/√Hz Sensor Size 19mm*46mm*91mm
Sampling Rate 1Hz, 20Hz, 1000Hz (configurable) Weight 112g
Measurement Range 1000nT-200,000nT Operating Temperature -15~55℃
Bandwidth 40Hz Dead Zone Horizontal<+/-9 °
Maximum Gradient Field 700nT/cm Max Slew Rate 20000nT/s
Power Supply 5V/1A Calibration Calibration-Free
Parameter Specification
Type Optically Pumped Rubidium Scalar Magnetometer
Magnetic Probe Size 15mm*15mm*30mm
Sensitivity 10pT/Hz1/2
Sensor Size 19mm*46mm*91mm
Sampling Rate 1Hz, 20Hz, 1000Hz (configurable)
Weight 112g
Measurement Range 1000nT-200,000nT
Operating Temperature -15~55℃
Bandwidth 40Hz
Dead Zone Horizontal<+/-9 °
Maximum Gradient Field 700nT/cm
Max Slew Rate 20000nT/s
Power Supply 5V/1A
Calibration Calibration-Free
