Ultra-Low Noise Current Source Modulation Module
The QHL series low-noise current source modulation module has 8 independent outputs, which can output the corresponding debugging current according to the modulation signal and has low noise .It is the preferred product for quantum precision measurement, laser control and other fields .Product Name: Ultra-Low Noise Current Source Modulation Module;
Specification Model: ULNCS-QHL1.0；
Name
Parameter
Name
Parameter
Supply
voltage
DC9-36V/2A
Output
Resolution
<3.43uA(1mV)
Number
of Input Channels
8CH
Output
Capacitor
<520pF
Number
of Output Channels
8CH
Working
Temperature
0--+60℃
Modulation
Frequency
DC--1MHz
Storage
Temperature
-20--+80℃
Noise
Less than 50pA√Hz
Working
Humidity
0--80%RH
Modulation
Voltage
±2V
Product
Size
142.8mm*167.3mm*63.9mm
Maximum
Output Load
10Ω
Product
Weight
830g
Maximum
Output Current
Iout(mA)=Vin(mV)/50(Ω)
