Quantum total field magnetometer
The Mozi Series quantum total field magnetometer (QTFM-Mozi) is a compact, highly sensitive geomagnetic scalar atomic magnetometer. It uses the direct relationship between the precession frequency of alkali metal atoms and the background magnetic field. It can detect small magnetic field variations accurately and stably. The compact, low-power package makes it suitable for a wide range of applications from magnetic observation stations to small mobile platforms(such as drones). It is an ideal choice for quantum precision measurement, industrial detection, mineral exploration and other fields of magnetic anomaly detection.Product name: Quantum total field magnetometer;
Specification Model: QTFM-Mozi1.0、QTFM-Mozi1.1;
Name
Parameter
Name
Parameter
Category
Geomagnetic Scalar
Atomic Optical Pump Magnetometer
Probe size
15mm*15mm*30mm
Sensitivity
2-20 pT/√Hz(Geomagnetic
environment)
Sensor size
19mm*46mm*91mm
Sampling Rate
1000Hz
Weight
112g
Operating Range
200nT-200,000nT
Working Temperature
-15 ~ 55ºC
Bandwidth
20-80Hz
Blind Spot
Horizontal < +/- 9º
Maximum
Gradient Field
700 nT/cm
Slope
10000nT/s
Power Supply
5V/1A
Calibration
No Calibration Required
